Weight, kg

70

Dimensions, (L×W×H), mm

570×505×480

Supply voltage, V

230±10%

Load on a tested alternator, A

0-100

Voltage of tested alternators, V

12/24

Drive power, kW

2,2

Load adjustment

Smoothly

Drive speed, rpm

0-3000

Drive speed adjustment

Smoothly

Drive speed direction

Left/right

Transmission type (drive/alternator)

Belt

Belt type

V belt; timing belt

Read parameters

Voltage; alternating current; constant current; drive rotation. COM voltage regulators: protocol; speed of exchange; protocol type; errors

Power of tested starters, kW

Up to 4

Voltage of tested starters, V

12/24

Measured parameters

Voltage; alternating current; сonstant current

Voltage measurement accuracy, V

0,1

Connection terminals

«COM» (LIN, BSS), «P-D», «DFM», «D+», «RLO», «C», «SIG», «F/67»

Voltage of tested voltage regulators, V

12/24

Tested parameters of voltage regulators

Stabilizing voltage; current rotor winding. COM voltage regulators: protocol; speed of exchange; regulator type; errors

Total check of voltage regulator, sec

30

Short circuit sound alert

Yes

Current measurement accuracy, A

0,1

Short circuit protection

Yes

Terminals of tested voltage regulators

«COM» (LIN, BSS), «P-D», «DFM», «D+», «RLO», «C», «SIG»

Battery model #1

Identified according to the battery dimensions (L×W×H), mm, maximum: 207×175×175

Display parameters

Stabilizing voltage; rotor winding current. COM voltage regulators: protocol; speed of exchange; type of regulator; errors. DFM (alternator load control indicator, %)
