Starteris* MTZ/ZIL/24V 4,5 kW

STARTERIO PLOKŠTELĖ VIETOJ PD-10 - 442201005

Starterinis priedas (plokštelė) naudojamas vietoje paleidimo varikliuko, PD-10UD (Puskačius). Lengvas montavimas.

Naudojamas ant MTZ.

123709001 / JUBANA      http://jubana.com/lt/spare-part/magneta-m124-b1-123709001/

М124B1-3728000-А

Pritaikymas:
For motors: PD-10

123708031 / Čekija MAGNETON kopija           http://catalog.jubana.com/lt/starter/123708031

MTZ, T-25, T-40, XTZ

Alternative products: 123708321 (12V 4,2 kW); 123708001 (12V 2,7 kW); 123708101 (12V 2,8 kW); 123708501 (12V 3,2 kW)

Voltage, V 12

Power, kW 3.2

Rotation CW

No./ teeth 10

Starter's type OSGR

123708021 / JUBANA

12V

0.70 KW

 CT-362/PD-10

123708501 / JUBANA /  http://catalog.jubana.com/lt/starter/123708501

MTZ, T-25, T-40, XTZ (with an additional solenoid)

Alternative products: 123708321 (12V 4,2 kW); 123708001 (12V 2,7 kW); 123708101 (12V 2,8 kW)

Voltage, V 12

Power, kW 3.2

Rotation CW

No./ teeth 10

Starter's ty[e OSGR

Product features:O.D [ mm ]                     77.40

Matching Brush set:             PSX158

Komplektas: Starteris + plokštelė
• Įtampa: 12V
• Galia: 3,2kW
• Sukimasis: CW / pagal laikrodžio rodyklę
• Dantu skaičius: 9
• Starterio tipas: OSGR / su reduktoriumi
• B+ (Terminalas 30): M10

Pastabos: Skirtas vietoj paleidimo variklio PD-10, kartu su papildoma tvirtinimo plokštele /  442201005

243708601 / JUBANA / http://catalog.jubana.com/lt/starter/243708601

BELARUS, GAZ, MAZ, PAZ, ZIL (with an additional soelnoid)

Alternative products: 243708201 with an additional solenoid (24V 4,5 kW); 243708361 (24V 8,1 kW); 243708101 (24V 4,5 kW); 243708501 with an additional solenoid (24V 5 kW)

Voltage 24V

Power 6.6KW

Rotation CW

No./ teeth 10

Starter's length 31 cm

123708280 / JUBANA /   http://catalog.jubana.com/lt/starter/123708280

Starter with reduction gear 12V 2,8kW; DT-20 (D-20)

Voltage 12 V

Power 2.8 KW

Rotation CCW

No./ teeth 10

Starter's type OSGR

123708001 /  JUBANA /             http://catalog.jubana.com/lt/starter/123708001

MTZ-80, -82, T-40, T-25, T-16

Alternative products: 123708101 (12V 2,8 kW); 123708501 with an additional solenoid (12V 3,2 kW); 123708031 (12V 3,2 kW) ; 123708321 (12V 4,2 kW)

Voltage [V]: 12

Rated Power [kW]: 2.7

Number of Teeth: 10

A [mm]: 100

B [mm]: 32

 Ilgis 203 mm nuo flanšo

123708002 / JUBANA /   http://catalog.jubana.com/lt/starter/123708002

Starter with reduction gear 12V 2,7kW; JUMZ-6КL, JUMZ-6КМ

Alternative products: 123708102 (12V 2,8 kW); 123708502 with an additional solenoid (12V 3,2 kW); 123708032 (12V 3,2 kW)

Voltage, V 12

Power, kW 2.7

Rotation CW

No./ teeth 10

Starter's type OSGR

243708501 / JUBANA / http://catalog.jubana.com/lt/starter/243708501

BELARUS, MAZ, PAZ, AMKODOR with an additional solenoid

Alternative products: 243708201 with an additional solenoid (24V 4,5 kW); 243708361 with an additional solenoid (24V 8,1 kW); 243708101 (24V 4,5 kW); 243708601 (24V 6,6 kW)

Voltage, 24 V

Power, 5 kW

Rotation CW

No./ teeth 10

Starter's length 25 cm

Skirtas vietoj paleidimo variklio PD-10
• Įtampa: 12V
• Galia: 3,2kW
• Sukimasis: CW / pagal laikrodžio rodyklę
• Dantu skaičius: 9
• Starterio tipas: OSGR / su reduktoriumi
• B+ (Terminalas 30): M10

Pastabos: Skirtas vietoj paleidimo variklio PD-10, kartu su papildoma tvirtinimo plokštele /  442201005

123708502 / JUBANA /  http://catalog.jubana.com/lt/starter/123708502

Starter with reduction gear 12V 3,2 kW; JUMZ (with an additional solenoid)

Alternative products: 123708002 (12V 2,7 kW); 123708102 (12V 2,8 kW)

Voltage, V 12

Power, kW 3.2

Rotation CW

No./ teeth 10

Starter's type OSGR

442201003 / JUBANA

Instead of:  PD-10

CT142T-10 / Baltarusija

Voltage - 24
Power -9,2
No./ teeth - 10
